3.5" Floppy disk Drive Units
3.5" Floppy Disk reader
resources page


Apple 3.5 Drive Apple Computer, Inc. Cupertino, California 95014 Model No. A9M0106 FCC ID : BCG96AA9M0106 Made in Japan

P/N 825-1304-A Serial Y9700QR

SUB-D 19-pin connexion

***



NEC FD1138H 716646-1-09-001

http://www.student.nada.kth.se/~d94-tan/pckort/necflopp.txt NEC Floppy Discs jumper Settings

includes Hitachi HA13493

it is only 19mm height



TEAC FD-235HG 6325-U p/n 19307763-25 s/n 8267309 5/25 MT TEAC CORP made in Thailand

Replace with Compaq Spare 3 Mode floppy (180788-201)

interface based on the 5510-00 TB6022F 9517KV Japan (pqfp-68) on the card 15532315-02A 525

equipment : 31-95 122138-02 K Compaq mechanical fixation

http://jope.fi/drives/



lecteur HxC

http://hxc2001.free.fr/floppy_drive_emulator/

http://obligement.free.fr/articles/hxcfloppyemulator_sd.php

http://hxc2001.com/download/floppy_drive_emulator/SDCard_HxC_Floppy_Emulator_User_Manual_FRA.pdf

https://www.smbaker.com/raspberry-pi-floppy-controller-board

https://www.vcfed.org/forum/forum/genres/pentium-first-generation/78662-no-fun-with-floppy-drives-in-a-modern-world



******
