Circuit Cellar serial programmer resources page
CCSP (Circuit Cellar Serial Programmer) eprom programmer has
been made by MicroMint but it is actually a device designed in 1985 by Steve
Ciarcia.
The circuitry is amazingly similar to the Mod-Mep 4 and many devices made by
JDR Microdevices. It uses nearly the same set of parts and the article describes
quite clearly and provides schematics of the device.
The only difference is that JDR chose to provide a PC interface card instead
of the serial interface in the original Ciarcia design. Ciarcia was affiliated
with JDR.
the user interface is a bit clumsy.
Curious if the circuitry for the later series of Mod Mup is similar.
Documentation
is available here (PDF- 50 pages - 3.58 Mb)
build
an intelligent serial eprom programmer Intel Article Reprint AR-525 ( PDF-
17 pages - 1019Kb)
info and code
is available here (ZIP Archive
- 121 Kb)
MODMEP4 information (PDF - 1.99 Mb)
http://arcarc.xmission.com/Test%20Equipment/Eprom%20Programmer%20Software/MEP4.ZIP
http://arcarc.xmission.com/Test%20Equipment/Eprom%20Programmer%20Software/ software
archive modmep4.zip
archive mod-mep4a.zip
If you look forward for other information about this topic, do
not hesitate to contact me by e-mail at: matthieu.benoit@free.fr
.
Important Notice: Also if you have any data about this topic, do not hesitate
to contribute to this page.
Si vous recherchez des informations pour ce sujet, vous pouvez me contacter par e-mail : matthieu.benoit@free.fr . De même si vous avez des informations sur ce sujet, n'hésitez pas à contribuer à cette page.
M-à-j: 26 mai, 2013.
